 Finding the right hot wire
|
Joined: Jun 2009
Posts: 84
Member
|
OP
Member
Joined: Jun 2009
Posts: 84 |
I've got my Garmin GPS mounted on the handlebars and have a power plug, but need to determine which hot wire to tap into. I only want it to work with the key turned on. Can anyoner suggest which wire I should use for my power ?
08 America, A/I &, Calif emissions "stuff" gone, air box removed & battery relocated, billet intakes, UNI Pods, 145 mains, 42 pilots, Stage 2 igniter, intminators, 813 cams, Progressive 412's, modified seat.
|
|
|
Re: Finding the right hot wire
|
Joined: Aug 2009
Posts: 1,669
Learned Hand
|
|
Learned Hand
Joined: Aug 2009
Posts: 1,669 |
When I installed heated grips I tapped into the tail light,as it only came on with key and I was able to place wires directly into existing connector without having to splice anything. Yellow and Black Not sure if it would be pratical for you application but it worked for me. There is also an accessory circuit that may work better.
|
|
|
Re: Finding the right hot wire
|
Joined: Mar 2007
Posts: 5,616
Check Pants
|
|
Check Pants
Joined: Mar 2007
Posts: 5,616 |
Use tha accessory circuit but add a relay so it's only powered when the key is on. Instructions for wiring that relay set up is in the tech vault.
SOLD: 07 Black BA, 39mm FCRs, TPUSA stage 1 head, TPUSA 813 cams, TPUSA 10.8:1 pistons, TTP #3 igniter, Specialty Spares Long Cannons, Tsukayu Hard Bags. 82HP/55tq
NEW: 19 Goldwing Tour DCT
|
|
|
Re: Finding the right hot wire
|
Joined: Aug 2009
Posts: 1,669
Learned Hand
|
|
Learned Hand
Joined: Aug 2009
Posts: 1,669 |
Yep, listen to Z, I remember now I used a relay also, picked one up at local autoparts store along with an inline fuse and another roll of 18 guage wire,all less than $15.
|
|
|
Re: Finding the right hot wire
|
Joined: Jun 2009
Posts: 84
Member
|
|
OP
Member
Joined: Jun 2009
Posts: 84 |
Thanks guys. I appreciate your help.
